Long Distance Teleopto

TeleoptoLD is developed by the demand of stable, long-distance transmission of optogenetic stimulation signal

For example, if you want to stimulate middle-large animal like marmoset and macaque monkey freely behaving in their large cage, the TeleoptoLD would be a perfect option

The following stimulation parameters are defined, sent to the headstage and trigger the stimulation by the TeleoptoLD software - initial delay (Delay), pulse width (Width), pulse interval (Intvl), number of pulses (N.pls), repeat interval (R.int), number of repeat (N.rep) and light power (Ampl.)

As well as the regular Teleopto, stimulation can be triggered by the push switch and also, sending TTL pulse to the Trg-in BNC. All the LED cannula used in the regular Teleopto is compatible with TeleoptoLD

It has 2 channel output, so you can independently stimulate left and right hemispere using Bilateral LED cannula or control both blue excitation and yellow inhibition by Two Color Cannula

- Stable long-distance transmission
- All parameters including light power can be sent wirelessly
- Compatible with all Teleopto LED cannulas
- Independent 2 channel

TeleoptoLD-set contents:

TeleoptoLDRV 1x TeleoptoLD Receiver
TeleoptoLDTM 1x TeleoptoLD Transmitter
TeleCharger 1x Teleopto Charger
TeleTool 1x Insertion Tool
TeleDummy 1x Dummy Receiver
3x any Teleopto cannula
1x TeleoptoLD Software
