- Holds 2 syringes up to 60 mL each, can be different sizes
- Both syringes operate in sync. Independent syringe operation, including "Push-Pull", available with the Dual Pump System
- Infusion rates from 1.436 µL/hr (1 mL syringe) to 7515 mL/hr (60 mL syringe)
- Easy-to-use keypad interface
- One-click program upload from "Pumping Program Generator" spreadsheet
- Space Saving Chassis: Foot print size of only 5 3/4" x 8 3/4"
- Won't take up unnecessary space on your laboratory or production bench
- Includes all the advanced functions and programming features of the NE-1000 series
- Disposable, Glass, Stainless Steel Syringes and Plumbing Supplies are sold separately.
Features of the NE-1000 Series of Syringe Pumps:
- Fully programmable; automation capable
- Operates stand-alone or from a computer. Cables sold separately
- Infusion and withdrawal
- Set a single pumping rate and/or dispensing volume
- Program up to 41 pumping phases that change pumping rates, set dispensing volumes, insert pauses, control and respond to external signals, sound the buzzer
- Network, control, and monitor up to 100 pumps with one computer
- Motor stall detection
- Dispensing accuracy of +/- 1%
- Unlimited lifetime technical support
NE-4000 Two Channel Syringe Pump Example Flow Rates
| Syringe Size |
Maximum Rate |
Minimum Rate |
| 0.5 µL |
90.39 µL/hr |
0.001 µL/hr |
| 1 mL |
187.4 mL/hr |
1.430 µL/hr |
| 3 mL |
793.4 mL/hr |
6.054 µL/hr |
| 5 mL |
1320 mL/hr |
10.08 µL/hr |
| 10 mL |
2153 mL/hr |
16.44 µL/hr |
| 20 mL |
3425 mL/hr |
26.14 µL/hr |
| 30 mL |
4468 mL/hr |
34.09 µL/hr |
| 60 mL |
7515 mL/hr |
57.34 µL/hr |
